Product Name: Itw | Viewsonic Portable Monitor VG1655 16" 1920x1080 FHD / 60Hz / IPS / 6.5ms / USB-C / Anti-Glare
16” USB-C Portable Business Monitor
> Compact, lightweight and portable
> Easily extend display to a larger screen from mobile devices
> 60W USB-C one cable solution for multimedia transfer and power charging
> Elegant, durable metallic design with a foldable stand
> Flexible display setup – work at any angle
Specification
Display
* Display Size (in.): 16
* Viewable Area (in.): 15.6
* Panel Type: IPS Technology
* Resolution: 1920 x 1080
* Resolution Type: FHD (Full HD)
* Static Contrast Ratio: 800:1 (typ)
* Dynamic Contrast Ratio: 50M:1
* Light Source: LED
* Brightness: 250 cd/m² (typ)
* Colors: 16.2M
* Color Space Support: 8 bit (6 bit + FRC)
* Aspect Ratio: 16:9
* Response Time (Typical GTG): 6.5ms
* Response Time (GTG w/OD): 6.551ms
* Response Time (Typical Tr+Tf): 30ms
* Viewing Angles: 178º horizontal, 178º vertical, CR>5; 170º horizontal, 170º vertical, CR>10
* Backlight Life (Hours): 15000 Hrs (Min)
* Curvature: Flat
* Refresh Rate (Hz): 60
* Low Blue Light: Software solution
* Color Gamut: NTSC: 45% size (Typ), sRGB: 64% size (Typ)
* Pixel Size: 0.179 mm (H) x 0.179 mm (V)
* Surface Treatment: Anti-Glare, Hard Coating (3H)
Compatibility
* PC Resolution (max): 1920x1080
* Mac® Resolution (max): 1920x1080
* PC Operating System: Windows 10/11 certified; macOS tested
* Mac® Resolution (min): 1920x1080
Connector
* USB 3.2 Type C DisplayPort Alt mode only : 2 (60W power charger)
* 3.5mm Audio Out: 1
* Mini HDMI: 1
* Power in: USB Type C (with video & data)
Audio
* Internal Speakers: 0.8Watts x2
Power
* Eco Mode (Conserve): 5.1W
* Eco Mode (optimized): 6W
* Consumption (typical): 7W
* Consumption (max): 7.3W
* Voltage: AC 100-240V
* Stand-by: 0.5W
* Power Supply: External Power Adaptor
Controls
* Physical Controls: Up, Right, Down, Left, Power
* On Screen Display: Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu
Operating Conditions
* Temperature: 32°F to 104°F (0°C to 40°C)
* Humidity (non-condensing): 20% to 90%
Input Signal
* Frequency Horizontal: 15 ~ 82KHz
* Frequency Vertical: 50 ~ 75Hz
Video Input
* Digital Sync: TMDS - mini HDMI (v1.4), Micro-Packet - Type C
Ergonomics
* Tilt (Forward/Back): 20º / 60º
Weight (imperial)
* Net (lbs): 1.8
* Net Without Stand (lbs): 1.8
* Gross (lbs): 4.8
Weight (metric)
* Net (kg): 0.82
* Net Without Stand (kg): 0.82
* Gross (kg): 2.2
Dimensions (imperial) (wxhxd)
* Packaging (in.): 17.3 x 11.3 x 3.5
* Physical (in.): 13.99 x 8.8 x 0.61
* Physical Without Stand (in.): 13.99 x 8.8 x 0.61
Dimensions (metric) (wxhxd)
* Packaging (mm): 440 x 288 x 89
* Physical (mm): 355.46 x 223.44 x 15.5
* Physical Without Stand (mm): 355.46 x 223.44 x 15.5
General
* Regulations: cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, NRCan, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, GEMS, VCCI, PSE(Adaptor), BIS
* PACKAGE CONTENTS: VG1655 x1, mini HDMI to HDMI Cable (v1.4; Male-Male) x1, USB Type-C Cable (Male-Male) x1, USB Type-C to Type-A 3.2 Gen1 Cable (Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1, Protect cover x1, Clean cloth x1
* Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
* Warranty: *Warranty offered may differ from market to market
* Power Management: Energy Star standards, EPEAT
