Product Name: ASUS TUF Gaming AX6000 Dual Band WiFi 6 Gaming Router
Key Feature
• Ultrafast WiFi 6 – Ultra WiFi speed up to 6000 Mbps and 4X network efficiency.
• Dual 2.5G Ports – Dual 2.5G ports with flexible WAN/LAN port configuration.
• Fast & Stable Wired Gaming – Dedicated gaming port to prioritize connected gaming device .
• ASUS AiMesh Support – Support AiMesh to create a whole-home mesh network.
• Tested Durability and Stable Operation – TUF Gaming AX6000 is built to be durable and undergoes verified testing to ensure reliable, stable operation.
Specification
Network Standard
• IEEE 802.11a
• IEEE 802.11b
• IEEE 802.11g
• WiFi 4 (802.11n)
• WiFi 5 (802.11ac)
• WiFi 6 (802.11ax)
• IPv4
• IPv6
Product Segment
• AX6000 ultimate AX performance : 1148+4804 Mbps
WiFi Data Rate
• 802.11a : up to 54 Mbps
• 802.11b : up to 11 Mbps
• 802.11g : up to 54 Mbps
• WiFi 6 (802.11ax) (2.4GHz) : up to 1148 Mbps
• WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps
Antenna: External antenna x 6
Transmit / Receive
• 2.4GHz 4x4
• 5GHz 4x4
Processor: 2.0 GHz quad-core processor
Memory
• 256 MB Flash
• 512 MB RAM
Boosts Speed
• OFDMA (Orthogonal Frequency Division Multiple Access)
• Beamforming: standard-based and universal
• 1024-QAM high data rate
• 20/40/80/160 MHz bandwidth
Operating Frequency: 2.4GHz / 5GHz
Operating Mode
• Wireless router mode
• Access point mode
• Media bridge mode
I/O Ports
• RJ45 for 2.5 Gigabits BaseT for WAN x 1,
• RJ45 for 2.5 Gigabits BaseT for LAN x 1,
• RJ45 for Gigabits BaseT for LAN x 4,
• USB 3.2 Gen 1 x 1,
Buttons: WPS Button, Reset Button, Power Button
LED Indicator
• Power x 1
• WiFi x 1
• 1G LAN x 4
• 2.5G WAN x 1
• 2.5G LAN x 1
Power Supply
• AC Input : 100V~240V (50~60Hz)
• DC Output : 12 V with max. 2.5 A current
Package Content
• TUF Gaming AX6000 Dual Band WiFi 6 router
• RJ-45 cable
• Power adapter
• Quick Start Guide
• Warranty card
Product Weight (g): 696g
Product Dimensions: 301.02 x 174 x 216 mm
AiMesh
• Primary AiMesh Router
• AiMesh Node
Game
• Game Boost / Acceleration
• Mobile Game Mode
Parental Control
• "Allow you to block access to unwanted websites and apps."
• Safe Browsing
• Customized Internet Schedule
Guest Network
• "The Guest Network provides Internet connection for guests but restricts access to your local network."
• Maximum Guest Network Rule : 2.4GHz x3, 5GHz x3
• Guest Network Connection Time Limit
Security
• AiProtection
• WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
• WPS
• Let's Encrypt
• DNS-over-TLS
• SSH
• Security Scan
Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection
• Router Security Assessment
• Malicious Site Blocking
• Two-Way IPS
• Infected Device Prevention and Blocking
VPN
• VPN Client L2TP
• VPN Client Open VPN
• VPN Client PPTP
• VPN Client WireGuard
• VPN Server IPSec
• VPN Server Open VPN
• VPN Server PPTP
• VPN Server WireGuard
• VPN Fusion
Traffic Control
Adaptive QoS
• Bandwidth Monitor
• Bandwidth Limiter
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
-- Maximum Traditional QoS Rule : 32
Traffic Monitor
• Real-time Traffic Monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor
Traffic Analyzer
• Traffic Analysis Period : Daily, Weekly, Monthly
• Website History
WAN
• Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
WAN Aggregation
• 3G / 4G LTE dongle
Port forwarding
• Maximum Port Forwarding Rule : 64
Port triggering
• Maximum Port Triggering Rule : 32
DMZ
DDNS
NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
LAN
• DHCP Server
• IGMP Snooping
• IPTV
• LAN Link Aggregation
Manually Assign IP Address
• Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
Wireless
• UTF-8 SSID
• WiFi MAC Address Filter
• Maximum MAC Filters : 64
• Wireless Scheduler
• Airtime Fairness
• RADIUS Client
• Universal Beamforming
• Explicit Beamforming
USB application
• File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
• Safely Remove Disk
• AiCloud
• Download Master
• AiDisk
• Media Server
• Time Machine
• Samba Server
• FTP Server
• Shared Folder Privileges
Administration
• Configuration Backup and Restore
• Diagnosis tools
• Feedback System
• System Log
• New Device Connect Notification
• Login Captcha
• Connection Diagnosis
• Auto Firmware Update
