Product Name: Itw | TP-link TL-SM5310-T 10G Base-T RJ45 SFP+ Module
10G BASE-T RJ45 SFP+ Module
* Support 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, and 100BASE-TX
* Transmit data up to 30m* at 10 Gbps (UTP cat.6a or above)
* Support DDM (Temperature and Voltage)
* Hot-Pluggable SFP+ Footprint Features
* Support TX Disable function
* Commercial Product Operating Temperature Range: 0-70°C
* Fully Metallic Enclosure for Low EMI
Specification
PACKAGE CONTENTS
* 10G BASE-T RJ45 SFP+ Module TL-SM5310-T
* Installation Guide
HARDWARE FEATURES
* Hot Swappable: Yes
MEDIA CONVERTER & MODULE
* Dimensions (W*D*H): 2.7*0.5*0.5 in (67.4*13.75*13.8 mm)
TRANSCEIVER
* Standards and Protocols: IEEE Std 802.3, 802.3ab, 802.3bz, 82.3an
* Power Supply: 3.3V
* Max. Cable Length
> 100BASE-TX: UTP cat .5 or above (max. 100m)
> 1000BASE-T/2.5GBASE-T/5GBASE-T: UTP cat.5e or above (max. 100m)
> 10GBASE-T: UTP cat.6a or above (max. 30m)
* Data Rate: 10.3 Gbps
* Port Type: 1× 10G RJ45 Port
* Safety & Emission: FCC, CE, RoHS
* Environment
> Operating Temperature: 0–70 ℃ (32–158 ℉)
> Storage Temperature: -40–85 ℃ (-40–185 ℉)
