Product Name: Itw | Gigabyte Bundle Motherboard AMD Ryzen 7 9800X3D with X870 Aorus Elite Wifi7 ATX AM5 DDR5
*** AMD Ryzen 7 9800X3D 8-Cores 16-Threads Desktop Processor without Cooler ***
General
> Name: AMD Ryzen™ 7 9800X3D
> Family: Ryzen
> Series: Ryzen 9000 Series
> Form Factor: Desktops, Boxed Processor
> Market Segment: Enthusiast Desktop
> AMD PRO Technologies: No
> Consumer Use: Yes
> Regional Availability: Global
> Former Codename: Granite Ridge AM5
> Architecture: Zen 5
> # of CPU Cores: 8
> Multithreading (SMT): Yes
> # of Threads: 16
> Max. Boost Clock: Up to 5.2 GHz
> Base Clock: 4.7 GHz
> L1 Cache: 640 KB
> L2 Cache: 8 MB
> L3 Cache: 96 MB
> Default TDP: 120W
> Processor Technology for CPU Cores: TSMC 4nm FinFET
> Processor Technology for I/O Die: TSMC 6nm FinFET
> Package Die Count: 2
> Unlocked for Overclocking: Yes
> AMD EXPO™ Memory Overclocking Technology: Yes
> Precision Boost Overdrive: Yes
> Curve Optimizer Voltage Offsets: Yes
> AMD Ryzen™ Master Support: Yes
> CPU Socket: AM5
> Supporting Chipsets: A620, X670E, X670, B650E, B650, X870E, X870, B840, B850
> CPU Boost Technology: Precision Boost 2
> Instruction Set: x86-64
> Supported Extensions: AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
> Thermal Solution (PIB): Not Included
> Recommended Cooler: Liquid cooler recommended for optimal performance
> Max. Operating Temperature (Tjmax): 95°C
> Launch Date: 11/07/2024
> *OS Support: Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit
Connectivity
> Native USB 3.2 Gen 2 (10Gbps) Ports: 4
> Native USB 2.0 (480Mbps) Ports: 1
> PCI Express® Version: PCIe® 5.0
> Native PCIe® Lanes (Total/Usable): 28 , 24
> NVMe Support: Boot, RAID0, RAID1, RAID5, RAID10
> System Memory Type: DDR5
> Memory Channels: 2
> Max. Memory: 192 GB
> System Memory Subtype: UDIMM
> Max Memory Speed
- 2x1R DDR5-5600
- 2x2R DDR5-5600
- 4x1R DDR5-3600
- 4x2R DDR5-3600
> ECC Support: Yes (Requires mobo support)
Graphics Capabilities
> Graphics Model: AMD Radeon™ Graphics
> Graphics Core Count: 2
> Graphics Frequency: 2200 MHz
> USB Type-C® DisplayPort™ Alternate Mode: Yes
Key Features
> Supported Technologies
- AMD EXPO™ Technology, AMD Ryzen™ Technologies
*** Gigabyte Motherboard X870 Aorus Elite Wifi7 ATX AM5 DDR5 ***
CPU
> AMD Socket AM5, support for: AMD Ryzen™ 9000 Series Processors / AMD Ryzen™ 8000 Series Processors / AMD Ryzen™ 7000 Series Processors
Chipset
> AMD X870
Memory
> Support for DDR5 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
> 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
> Dual channel memory architecture
> Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
> Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
Audio
> Realtek® ALC1220 CODEC
* The back panel line out jack supports DSD audio.
> High Definition Audio
> 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
> Support for S/PDIF Out
Wireless Communication module
> MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.4
- Support for 11be 160MHz wireless standard
> Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.4
- Support for 11be 160MHz wireless standard (Actual data rate may vary depending on environment and equipment)
* Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10)
**Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations.
Back Panel Connectors
> 1 x Q-Flash Plus button
> 1 x HDMI port (Note)
> 2 x antenna connectors (2T2R)
> 2 x USB4® USB Type-C® ports (DisplayPort (Note))
> 2 x USB 3.2 Gen 2 Type-A ports (red)
> 4 x USB 3.2 Gen 1 ports
> 4 x USB 2.0/1.1 ports
> 1 x RJ-45 port
> 1 x optical S/PDIF Out connector
> 2 x audio jacks
Form Factor
> ATX; 30.5cm x 24.4cm
