Product Name: Itw | ASUS Motherboard ROG Strix B850-A Gaming Wifi ATX AM5 DDR5
Specification
Model
> ROG STRIX B850-A GAMING WIFI
CPU
> AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
Chipset
> AMD B850
Memory
> 4 x DIMM slots, max. 192GB, DDR5
> Supports up to 8000+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors ECC and Non-ECC, Un-buffered DIMM
> Dual channel memory architecture
> Supports AMD Extended Profiles for Overclocking (EXPO™)
> ASUS Enhanced Memory Profile (AEMP)
Graphics
> 1 x DisplayPort
> 1 x HDMI™ port
Expansion Slots
> AMD Ryzen™ 9000 & 7000 Series Desktop Processors
- 1 x PCIe 5.0 x16 slot with Q-Release Slim
> AMD Ryzen™ 8000 Series Desktop Processors
- 1 x PCIe 5.0 x16 slot with Q-Rlease Slim (supports PCIe 4.0 x8 or x4 mode)
> AMD B850 Chipset
- 1 x PCIe 4.0 x16 slot (supports x4 mode)
Storage
> Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports
> AMD Ryzen™ 7000 & 9000 Series Desktop Processors
- M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 5.0x4 mode)
- M.2_2 (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
> AMD Ryzen™ 8000 Series Desktop Processors
- M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 4.0x4 mode)
- M.2_2 (Key M), type 2280/22110 (supports PCIe 4.0 x4/x2 mode)
> AMD B850 Chipset
- M.2_3 (Key M), type 2280 (supports PCIe 4.0 x4)
- M.2_4 (Key M), type 2280 (supports PCIe 4.0 x4)
- 2 x SATA 6Gb/s ports
> AMD RAIDXpert2 Technology
- Ryzen™ 9000 Series Processors: RAID 0/1/5/10
- Ryzen™ 8000 Series Processors: RAID 0/1
- Ryzen™ 7000 Series Processors: RAID 0/1/10
Ethernet
> 1 x Intel® 2.5Gb Ethernet
> ASUS LANGuard
Wireless & Bluetooth
> Wi-Fi 7
> 2x2 Wi-Fi 7 (802.11be)
> Supports 2.4/5/6GHz frequency band
> Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
> Bluetooth® v5.4
USB
> Rear USB (Total 10 ports)
- 1 x USB 20Gbps port (1 x USB Type-C®)
- 3 x USB 10Gbps ports (2 x Type-A + 1 x USB Type-C®)
- 4 x USB 5Gbps ports (4 x Type-A)
- 2 x USB 2.0 ports (2 x Type-A)
> Front USB (Total 7 ports)
- 1 x USB 10Gbps connector (supports USB Type-C®)
- 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
- 2 x USB 2.0 headers support 4 additional USB 2.0 ports
Audio
> ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback on front panel
> Audio Features
- SupremeFX Shielding Technology
- Savitech SV3H712 AMP
- Rear optical S/PDIF out port
- Premium audio capacitors
- Audio cover
Back Panel I/O Ports
> 1 x USB 20Gbps port (1 x USB Type-C®)
> 3 x USB 10Gbps ports (2 x Type-A + 1 x USB Type-C®)
> 4 x USB 5Gbps ports (4 x Type-A)
> 2 x USB 2.0 ports (2 x Type-A)
> 1 x DisplayPort
> 1 x HDMI™ port
> 1 x Wi-Fi module
> 1 x Intel® 2.5Gb Ethernet port
> 2 x Audio jacks
> 1 x Optical S/PDIF out port
> 1 x BIOS FlashBack™ button
> 1 x Clear CMOS button
Form Factor
> ATX / 12-inch x 9.6-inch (30.5cm x 24.4cm)
