MSI PRO B760M-P DDR5 LGA1700 Micro-ATX Motherboard for Intel 14th/13th/12th Gen

Upgrade your PC build with the MSI PRO B760M-P Motherboard, designed for reliability and performance. Built on the Intel® B760 chipset, this motherboard supports the latest Intel® Core™ 14th/13th/12th Gen processors and fast DDR5 memory, making it ideal for productivity, gaming, and workstation setups. Available from IT World (itw), your trusted local PC hardware supplier.

🖥 Processor & Chipset Support

• ⚙ Chipset: Intel® B760

• 🔧 CPU Socket: LGA 1700

• 💻 Supports Intel® Core™ 14th / 13th / 12th Gen Processors

• 🔹 Also supports Intel® Pentium® Gold and Celeron® Processors

⚡ High-Speed DDR5 Memory

• 🧠 4× DDR5 DIMM Slots

• 📦 Maximum Memory Capacity: 256GB

• 🚀 Memory Support:

• DDR5 6800+(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC)

• DDR5 5600 / 5400 / 5200 / 5000 / 4800 MHz (JEDEC)

• ⚡ Supports Intel® XMP 3.0 Overclocking

• 🔁 Dual-Channel Memory Architecture

🎮 Integrated Graphics Output

(Available only with CPUs that support integrated graphics)

• 🖥 1× HDMI™ (4K @ 30Hz)

• 🖥 1× DisplayPort (4K @ 60Hz)

• 🖥 1× VGA

🚀 Expansion Slots

• 🔧 1× PCIe 4.0 x16 Slot (From CPU)

• 🔧 2× PCIe 4.0 x1 Slots (From Chipset)

💾 Storage & RAID Support

• ⚡ 2× M.2 Slots

• M.2_1 (PCIe 4.0 x4 from CPU)

• M.2_2 (PCIe 4.0 x4 / SATA from Chipset)

• 💽 4× SATA 6Gb/s Ports

📊 RAID Support:

• RAID 0 / 1 / 5 / 10 for SATA storage devices

🔌 USB Connectivity

• 🔹 USB 10Gbps Type-C (Rear) – 1 Port

• 🔹 USB 5Gbps Type-A (Rear) – 1 Port

• 🔹 USB 5Gbps Type-A (Front) – 2 Ports

• 🔹 USB 2.0 (Rear) – 4 Ports

• 🔹 USB 2.0 (Front) – 4 Ports

🌐 Networking & Audio

• 🌐 Realtek® RTL8111H Gigabit LAN

• 🎧 Realtek® ALC897 Audio Codec

• 🔊 7.1 Channel High Definition Audio

🧩 Internal Connectors

• 🔌 1× ATX Power Connector

• 🔌 1× CPU Power Connector

• 🌪 1× CPU Fan Header

• 🌪 2× System Fan Headers

• 🔘 2× Front Panel Connectors

• 🔒 1× Chassis Intrusion Header

• 🎧 1× Front Audio Header

• 🖨 1× Printer Port (LPT)

• 🖧 1× COM Port

• 🌈 1× RGB LED Connector

• 🔐 1× TPM Pin Header (TPM 2.0 Support)

💡 Diagnostic & LED Features

• 🔧 4× EZ Debug LEDs for quick troubleshooting

🖥 Rear I/O Ports

• VGA

• DisplayPort

• HDMI™

• USB 2.0 Ports

• USB 3.2 Gen1 5Gbps Type-A

• USB 3.2 Gen2 10Gbps Type-C

• LAN Port

• Audio Connectors

• Keyboard / Mouse Port

💻 Operating System Support

• Windows® 11 64-bit

• Windows® 10 64-bit
