🤍 Premium White Theme ATX Design
Built with a silver-white color scheme – perfect for showcasing high-end white PC builds.
🚀 Next-Gen AMD Platform
🔹 AMD X870E Chipset
🔹 AM5 Socket – Supports Ryzen™ 9000 / 8000 / 7000 Series
🔹 Supplemental PCIe Power (8-pin)
🔹 3× PCIe slots
• PCIe 5.0 x16 (from CPU)
• PCIe 3.0 x1 (from chipset)
• PCIe 4.0 x4 (from chipset)
🧠 Extreme DDR5 Memory Performance
🔹 4× DDR5 UDIMM – up to 256GB
🔹 DDR5 8400 – 5600 (OC) / 5600 – 4800 (JEDEC)
🔹 AMD EXPO™ & Memory OC Support
🔹 Dual-channel, Non-ECC, Un-buffered
🎮 Display & USB4 Connectivity
🔹 HDMI™ 2.1 – up to 8K 60Hz*
🔹 2× Type-C DisplayPort (USB4 – DP 1.4 HBR3, up to 4K 60Hz)*
(*Requires CPU with integrated graphics)
⚡ Ultra-Fast Storage Options
🔹 4× M.2 slots
• 2× PCIe 5.0 x4 (from CPU)
• 2× PCIe 4.0 x4 (from chipset)
🔹 4× SATA 6G
🔹 RAID Support
• SATA: RAID 0 / 1 / 10
• M.2 NVMe: RAID 0 / 1 / 5 / 10**
(**Depends on CPU series)
🌐 Flagship Networking
📡 True Wi-Fi 7 + Bluetooth 5.4 (M.2 Key-E pre-installed)
⚡ Realtek® 8126 5G LAN
🔹 MU-MIMO, 2.4GHz / 5GHz / 6GHz up to 5.8Gbps
🔊 High-End Audio
🎧 Realtek® ALC4080 – 7.1 Channel USB High-Performance Audio
🔹 Optical S/PDIF Out
🔌 High-Speed USB Connectivity
Rear:
🔹 2× USB 40Gbps Type-C (USB4)
🔹 1× USB 10Gbps Type-C
🔹 5× USB 10Gbps Type-A
🔹 4× USB 2.0
Front:
🔹 1× USB 20Gbps Type-C
🔹 4× USB 5Gbps Type-A
🔹 4× USB 2.0
🛠 Internal Connectors & Cooling Support
🔹 2× CPU Power + ATX Power
🔹 CPU Fan + PUMP_SYS Fan
🔹 6× System Fan headers
🔹 3× Addressable V2 RGB + 1× RGB LED
🔹 TPM 2.0 header
🔹 Front panel & front audio
🔹 ARGB+FAN+USB2.0 Header (JAF_2)
🔹 Chassis Intrusion
💡 EZ DIY & Debug Features
🔹 4× EZ Debug LED
🔹 EZ Digi-Debug LED
🔹 Flash BIOS Button
🔹 Clear CMOS Button
🖥 Back Panel I/O
🔹 HDMI™
🔹 USB 40Gbps Type-C
🔹 USB 10Gbps Type-A & Type-C
🔹 USB 2.0
🔹 5G LAN
🔹 Wi-Fi / Bluetooth antenna
🔹 Optical S/PDIF Out
🔹 Audio ports
🧩 Form Factor & OS Support
📏 ATX – 243.84mm × 304.8mm
🪟 Windows® 11 64-bit Ready
⚠️ Reminders:
1️⃣ Please record a full unboxing video as proof in case of issues.
2️⃣ Verify the delivery rider’s ID or take a photo with your payment for security.
