Product Name: Itw | Intel Core i3-14100 12M Cache, up to 4.70Ghz Desktop Processor
Specification
Essentials
* Product Collection: Intel® Core™ i5 Processors (14th gen)
* Code Name: Products formerly Raptor Lake
* Vertical Segment: Desktop
* Processor Number: i5-14400
* Lithography: Intel 7
CPU Specifications
* Total Cores: 10
* # of Performance-cores: 6
* # of Efficient-cores: 4
* Total Threads: 16
* Max Turbo Frequency: 4.7 GHz
* Performance-core Max Turbo Frequency: 4.7 GHz
* Efficient-core Max Turbo Frequency: 3.5 GHz
* Performance-core Base Frequency: 2.5 GHz
* Efficient-core Base Frequency: 1.8 GHz
* Cache: 20 MB Intel® Smart Cache
* Total L2 Cache: 9.5 MB
* Processor Base Power: 65 W
* Maximum Turbo Power: 148 W
Supplemental Information
* Marketing Status: Launched
* Launch Date: Q1'24
* Embedded Options Available: Yes
* Use Conditions: PC/Client/Tablet
Memory Specifications
* Max Memory Size (dependent on memory type): 192 GB
* Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
* Max # of Memory Channels: 2
* Max Memory Bandwidth: 76.8 GB/s
GPU Specifications
* GPU Name‡: Intel® UHD Graphics 730
* Graphics Max Dynamic Frequency: 1.55 GHz
* Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
* Execution Units: 24
* Max Resolution (HDMI)‡: 4096 x 2160 @ 60Hz
* Max Resolution (DP)‡: 7680 x 4320 @ 60Hz
* Max Resolution (eDP - Integrated Flat Panel)‡: 5120 x 3200 @ 120Hz
* DirectX* Support: 12
* OpenGL* Support: 4.5
* OpenCL* Support: 3.0
* Multi-Format Codec Engines: 1
* Intel® Quick Sync Video: Yes
* Intel® Clear Video HD Technology: Yes
* # of Displays Supported ‡: 4
* Device ID: 0x4682/0xA782
Expansion Options
* Direct Media Interface (DMI) Revision: 4.0
* Max # of DMI Lanes: 8
* Scalability: 1S Only
* PCI Express Revision: 5.0 and 4.0
* PCI Express Configurations ‡: Up to 1x16+4, 2x8+4
* Max # of PCI Express Lanes: 20
Package Specifications
* Sockets Supported: FCLGA1700
* Max CPU Configuration: 1
* Thermal Solution Specification: PCG 2020C
* TJUNCTION: 100°C
* Package Size: 45.0 mm x 37.5 mm
* Max Operating Temperature: 100 °C
Advanced Technologies
* Intel® Gaussian & Neural Accelerator: 3.0
* Intel® Thread Director: Yes
* Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
* Intel® Speed Shift Technology: Yes
* Intel® Turbo Boost Technology ‡: 2.0
* Intel® Hyper-Threading Technology ‡: Yes
* Intel® 64 ‡: Yes
* Instruction Set: 64-bit
* Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
* Idle States: Yes
* Enhanced Intel SpeedStep® Technology: Yes
* Thermal Monitoring Technologies: Yes
* Intel® Volume Management Device (VMD): Yes
Security & Reliability
* Intel® Standard Manageability (ISM) ‡: Yes
* Intel® Control-Flow Enforcement Technology: Yes
* Intel® AES New Instructions: Yes
* Secure Key: Yes
* Intel® OS Guard: Yes
* Execute Disable Bit ‡: Yes
* Intel® Boot Guard: Yes
* Mode-based Execute Control (MBEC): Yes
* Intel® Virtualization Technology (VT-x) ‡: Yes
* Intel® Virtualization Technology for Directed I/O (VT-d) ‡: Yes
* Intel® VT-x with Extended Page Tables (EPT) ‡: Yes
