🔥 X3D Turbo Mode
• Unleash new era gaming performance
🧠 CPU Support (AM5 Socket)
• Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
• Chipset: AMD B840
⚡ Power & Stability
• Digital 5+2+2 Phases VRM Solution
💾 DDR5 Memory Support
• Dual Channel DDR5
• 2x DIMM slots, up to 128GB
• Supports AMD EXPO™ & XMP
• DDR5 speeds: 7600(O.C.) to 4400 MT/s
🎮 Graphics Output
• 1x DisplayPort (up to 3840x2160@144Hz, DP 1.4, HDR)
• 1x HDMI (up to 4096x2160@60Hz, HDMI 2.1, HDR, HDCP 2.3)
🌐 Fast Networking & Wireless
• 2.5GbE LAN
• Wi-Fi 6 (Realtek RTL8851BE)
• Bluetooth 5.3
❄️ Cooling & Thermal Design
• VRM Thermal Armor Advanced
• M.2 Thermal Guard
🔧 EZ-Latch Tool-Free Design
• PCIe & M.2 slots with quick release & screwless design
• M.2 heatsinks with screwless design
💽 Storage Options
• 2x M.2 Slots (CPU + Chipset)
• 4x SATA 6Gb/s
• RAID 0/1/5/10 for NVMe (RAID 5 for Ryzen 9000 only)
• RAID 0/1/10 for SATA
🔌 Expansion Slots
• 1x PCIe x16 (CPU)
• 1x PCIe x16 (Chipset, x4)
• PCIe UD Slot with 10X strength for better durability & heat dissipation
🔊 Audio
• Realtek® Audio CODEC
• 2/4/5.1/7.1-channel HD Audio
🧩 USB & Connectivity
• Back Panel:
– 2x USB 3.2 Gen 1
– 4x USB 2.0/1.1
– HDMI, DisplayPort
– RJ-45 LAN
– Q-Flash Plus Button
• Internal Headers:
– USB Type-C® (USB 3.2 Gen 1)
– USB 3.2 Gen 1
– USB 2.0/1.1
🛠️ BIOS & Utilities
• AMI UEFI BIOS (256 Mbit)
• Q-Flash & Q-Flash Plus
• GIGABYTE Control Center (GCC)
• Smart Backup
📐 Form Factor
• Micro-ATX: 24.4 x 24.4 cm
