📡 Product Overview
Experience next-generation wireless performance with the TP-Link Omada EAP787 🚀
This Wi-Fi 7 tri-band ceiling-mount access point is built for high-density enterprise and professional environments, delivering ultra-fast speeds, low latency, and centralized cloud management via Omada SDN.
✨ Key Features
⚡ BE15000 Tri-Band Wi-Fi 7 – Up to 15 Gbps total speed
📶 Tri-Band 8-Stream Performance
• 6 GHz: up to 5765 Mbps
• 5 GHz: up to 8648 Mbps
• 2.4 GHz: up to 688 Mbps
🧠 Dedicated RF Scanning – Real-time spectrum monitoring & interference avoidance
📡 Enhanced 6 GHz with AFC – Stronger signal & wider coverage
🔌 10G / 2.5G Ethernet Port – High-speed wired backbone
🧩 Advanced Wi-Fi 7 Tech – 320 MHz bandwidth, MLO, Multi-RUs, 4K-QAM
👥 High-Density Ready – Supports 510+ concurrent clients
🏢 Wide Coverage – Up to 2050 ft² (190 m²)
☁️ Omada SDN – Centralized cloud, hardware, or software controller
📍 Flexible Mounting – Ceiling, wall, or junction box (kits included)
🔧 Hardware Specifications
Interface: 1× 10G/2.5G Ethernet Port
Power Supply:
802.3bt / 802.3at PoE
12V / 2.5A DC (adapter not included)
Max Power Consumption:
29 W (PoE)
24.5 W (DC)
Antennas:
2.4 GHz: 2× 4.0 dBi
5 GHz: 4× 5.0 dBi
6 GHz: 2× 5.0 dBi
Bluetooth: Yes (internal antenna module)
Button: Reset
🌐 Wireless & Security Features
Standards: IEEE 802.11 a/b/g/n/ac/ax/be
Wireless Functions:
MU-MIMO, OFDMA, Mesh, Seamless Roaming (802.11k/v/r), Beamforming, Load Balance
Security:
WPA / WPA2 / WPA3 (Personal & Enterprise), VLAN, Captive Portal, Rogue AP Detection
Management:
Omada App, Cloud Access, SNMP v1/v2c/v3, Web-based Management, Syslog
