Product Name: ITW | Synology DiskStation DS423+ 4-Bays Compact Data Management Solution Desktop NAS
Specification
HARDWARE SPECS
CPU
✎ CPU Model: Intel Celeron J4125
✎ CPU Quantity: 1
✎ CPU Architecture: 64-bit
✎ CPU Frequency: 4-core 2.0 (base) / 2.7 (turbo) GHz
✎ Hardware Encryption Engine (AES-NI): Yes
Memory
✎ System Memory: 2 GB DDR4 non-ECC SODIMM
✎ Total Memory Slots: 1
✎ Maximum Memory Capacity: 6 GB (2 GB + 4 GB)
Storage
✎ Drive Bays: 4
✎ M.2 Drive Slots: 2 (NVMe)
✎ Compatible Drive Type* (See all supported drives)
■ 3.5" SATA HDD
■ 2.5" SATA SSD
■ M.2 2280 NVMe SSD
✎ Hot Swappable Drive*: Yes
External Ports
✎ RJ-45 1GbE LAN Port*: 2 (with Link Aggregation / Failover support)
✎ USB 3.2 Gen 1 Port*: 2
File System
✎ Internal Drives
■ Btrfs
■ EXT4
✎ External Drives
■ Btrfs
■ EXT4
■ EXT3
■ FAT
■ NTFS
■ HFS+
■ exFAT
Appearance
✎ Size (Height x Width x Depth): 166 mm x 199 mm x 223 mm
✎ Weight: 2.18 kg
Others
✎ System Fan: 92 mm x 92 mm x 2 pcs
✎ Fan Speed Mode
■ Full-Speed Mode
■ Cool Mode
■ Quiet Mode
✎ Brightness Adjustable Front LED Indicators: Yes
✎ Power Recovery: Yes
✎ Noise Level*: 19.8 dB(A)
✎ Scheduled Power On / Off: Yes
✎ Wake on LAN / WAN: Yes
✎ Power Supply Unit / Adapter: 90 W
✎ AC Input Power Voltage: 100V to 240V AC
✎ Power Frequency: 50/60 Hz, Single Phase
✎ Power Consumption
■ 28.3 W (Access)
■ 8.45 W (HDD Hibernation)
✎ British Thermal Unit
■ 96.5 BTU/hr (Access)
■ 28.81 BTU/hr (HDD Hibernation)
Temperature
✎ Operating Temperature: 0°C to 40°C (32°F to 104°F)
✎ Storage Temperature: -20°C to 60°C (-5°F to 140°F)
✎ Relative Humidity: 5% to 95% RH
SOFTWARE SPECS
DSM Specifications
Storage Management
✎ Maximum Single Volume Size*: 108 TB
✎ Maximum Internal Volume Number: 64
✎ M.2 SSD Storage Pool Support*: Yes
✎ SSD Read / Write Cache (White Paper): Yes
✎ SSD TRIM: Yes
✎ Supported RAID Type
■ Synology Hybrid RAID
■ Basic
■ JBOD
■ RAID 0
■ RAID 1
■ RAID 5
■ RAID 6
■ RAID 10
✎ RAID Migration
■ Basic to RAID 1
■ Basic to RAID 5
■ RAID 1 to RAID 5
■ RAID 5 to RAID 6
✎ Volume Expansion with Larger HDDs
■ Synology Hybrid RAID
■ RAID 1
■ RAID 5
■ RAID 6
■ RAID 10
✎ Volume Expansion by Adding a HDD
■ Synology Hybrid RAID
■ JBOD
■ RAID 5
✎ Global Hot Spare Supported RAID Type
■ Synology Hybrid RAID
■ RAID 1
■ RAID 5
File Services
✎ File Protocol: SMB/AFP/NFS/FTP/WebDAV
✎ Maximum Concurrent SMB/AFP/FTP Connections: 500
✎ Maximum Concurrent SMB/AFP/FTP Connections (with RAM expansion): 1,500
✎ Windows Access Control List (ACL) Integration: Yes
✎ NFS Kerberos Authentication: Yes
Account & Shared Folder
✎ Maximum Local User Accounts: 2,048
✎ Maximum Local Groups: 256
✎ Maximum Shared Folder: 512
✎ Maximum Shared Folder Sync Tasks: 8
Hybrid Share
✎ Hybrid Share Folder Number: 10
High Availability
✎ Synology High Availability: Yes
Log Center
✎ Syslog Events per Second: 800
Virtualization
✎ VMware vSphere with VAAI: Yes
✎ Citrix Ready: Yes
✎ OpenStack: Yes
General
✎ Networking Protocols: SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
✎ Supported Browsers
■ Google Chrome
■ Firefox
■ Microsoft Edge
■ Safari
✎ Supported Language: English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文
✎ Antivirus by McAfee (Trial): Yes
✎ Central Management System: Yes
Synology Chat
✎ Maximum Number of Concurrent Users: 100
✎ Document Viewer: Yes
Download Station
✎ Maximum Concurrent Download Tasks: 80
SAN Manager
✎ Maximum iSCSI Target Number: 128
✎ Maximum LUN: 256
✎ LUN Clone/Snapshot, Windows ODX: Yes
Media Server
✎ DLNA Compliance: Yes
Synology Photos
✎ Facial Recognition: Yes
Snapshot Replication
✎ Maximum Snapshots per Shared Folder: 1,024
✎ Maximum of System Snapshots: 65,536
Surveillance Station
✎ Maximum IP cam (Licenses required): 40 (including 2 Free License) (see all supported IP cameras)
✎ Total FPS (H.264)
■ 1200 FPS @ 720p (1280x720)
■ 800 FPS @ 1080p (1920x1080)
■ 350 FPS @ 3M (2048x1536)
■ 280 FPS @ 5M (2591x1944)
■ 170 FPS @ 4K (3840x2160)
✎ Total FPS (H.265)
■ 1200 FPS @ 720p (1280x720)
■ 1200 FPS @ 1080p (1920x1080)
■ 600 FPS @ 3M (2048x1536)
■ 480 FPS @ 5M (2591x1944)
■ 200 FPS @ 4K (3840x2160)
Synology Office
✎ Maximum Users: 1,200
✎ Video Station: Yes
Virtual Machine Manager
✎ Recommended Virtual Machine Instances: 2
✎ Recommended Virtual DSM Number (Licenses required): 2 (including 1 Free License)
VPN Server
✎ Maximum Connections: 40
