Synology DiskStation DS224+ Compact 2-Bays Desktop Network Attached Storage (NAS) (DS224+)

Product Name: ITW | Synology DiskStation DS220+/DS224+ Compact 2-Bays Desktop Network Attached Storage (NAS)

*** Synology DiskStation DS220+ Compact 2-Bays Desktop Network Attached Storage (NAS) ***

Specification

CPU

* CPU Model: Intel Celeron J4025

* CPU Quantity: 1

* CPU Architecture: 64-bit

* CPU Frequency: 2-core 2.0 (base) / 2.9 (burst) GHz

* Hardware Encryption Engine (AES-NI): Yes

Memory

* System Memory: 2 GB DDR4 non-ECC

* Total Memory Slots: 1

* Maximum Memory Capacity: 6 GB (2 GB + 4 GB)

Storage

* Drive Bays: 2

* Compatible Drive Type* (See all supported drives)

- 3.5" SATA HDD

- 2.5" SATA HDD

- 2.5" SATA SSD

* Hot Swappable Drive*: Yes

External Ports

* RJ-45 1GbE LAN Port: 2 (with Link Aggregation / Failover support)

* USB 3.2 Gen 1 Port*: 2

* USB Copy: Yes

File System

* Internal Drives

- Btrfs

- EXT4

* External Drives

- Btrfs

- EXT4

- EXT3

- FAT

- NTFS

- HFS+

- exFAT

Appearance

* Size (Height x Width x Depth): 165 mm x 108 mm x 232.2 mm

* Weight: 1.30 kg

Others

* System Fan: 92 mm x 92 mm x 1 pcs

* Fan Speed Mode

- Full-Speed Mode

- Cool Mode

- Quiet Mode

* Brightness Adjustable Front LED Indicators: Yes

* Power Recover: Yes

* Noise Level*: 19.3 dB(A)

* Scheduled Power On / Off: Yes

* Wake on LAN / WAN: Yes

* Power Supply Unit / Adapter: 60 W

* AC Input Power Voltage: 100V to 240V AC

* Power Frequency: 50/60 Hz, Single Phase

* Power Consumption

- 14.69 W (Access)

- 4.41 W (HDD Hibernation)

* British Thermal Unit

- 50.12 BTU/hr (Access)

- 15.05 BTU/hr (HDD Hibernation)

Temperature

* Operating Temperature: 0°C to 40°C (32°F to 104°F)

* Storage Temperature: -20°C to 60°C (-5°F to 140°F)

* Relative Humidity: 5% to 95% RH

*** Synology DiskStation DS224+ Compact 2-Bays Desktop Network Attached Storage (NAS) ***

Specification

HARDWARE SPECS

CPU

* CPU Model: Intel Celeron J4125

* CPU Quantity: 1

* CPU Architecture: 64-bit

* CPU Frequency: 4-core 2.0 (base) / 2.7 (burst) GHz

* Hardware Encryption Engine (AES-NI): Yes

Memory

* System Memory: 2 GB DDR4 non-ECC

* Total Memory Slots: 1

* Maximum Memory Capacity: 6 GB (2 GB + 4 GB)

Storage

* Drive Bays: 2

* Compatible Drive Type* (See all supported drives)

- 3.5" SATA HDD

- 2.5" SATA SSD

* Hot Swappable Drive*: Yes

External Ports

* RJ-45 1GbE LAN Port: 2 (with Link Aggregation / Failover support)

* USB 3.2 Gen 1 Port*: 2

* USB Copy: Yes

File System

* Internal Drives

- Btrfs

- EXT4

* External Drives

- Btrfs

- EXT4

- EXT3

- FAT

- NTFS

- HFS+

- exFAT

Appearance

* Size (Height x Width x Depth): 165 mm x 108 mm x 232.2 mm

* Weight: 1.30 kg

Temperature

* Operating Temperature: 0°C to 40°C (32°F to 104°F)

* Storage Temperature: -20°C to 60°C (-5°F to 140°F)

* Relative Humidity: 5% to 95% RH

Others

* System Fan: 92 mm x 92 mm x 1 pcs

* Fan Speed Mode

- Full-Speed Mode

- Cool Mode

- Quiet Mode

* Brightness Adjustable Front LED Indicators: Yes

* Power Recovery: Yes

* Noise Level*: 22 dB(A)

* Scheduled Power On / Off: Yes

* Wake on LAN / WAN: Yes

* Power Supply Unit / Adapter: 60 W

* AC Input Power Voltage: 100V to 240V AC

* Power Frequency: 50/60 Hz, Single Phase

* Power Consumption

- 14.69 W (Access)

- 4.41 W (HDD Hibernation)

* British Thermal Unit

- 50.09 BTU/hr (Access)

- 15.04 BTU/hr (HDD Hibernation)

SOFTWARE SPECS

DSM SPECS

* Storage Management

* Maximum Single Volume Size*: 108 TB

* Maximum Internal Volume Number: 64

* SSD TRIM

* Supported RAID Type

- Synology Hybrid RAID

- Basic

- JBOD

- RAID 0

- RAID 1

* RAID Migration: Basic to RAID 1

* Volume Expansion with Larger HDDs

- Synology Hybrid RAID

- RAID 1

* Volume Expansion by Adding a HDD: Synology Hybrid RAID

File Services

* File Protocol: SMB/AFP/NFS/FTP/WebDAV

* Maximum Concurrent SMB/AFP/FTP Connections: 500

* Maximum Concurrent SMB/AFP/FTP Connections (with RAM expansion): 1,500

* Windows Access Control List (ACL) Integration: Yes

* NFS Kerberos Authentication: Yes

Account & Shared Folder

* Maximum Local User Accounts: 2,048

* Maximum Local Groups: 256

* Maximum Shared Folder: 256

* Maximum Shared Folder Sync Tasks: 8

Hybrid Share

* Hybrid Share Folder Number: 10

Hyper Backup

* Data & Folder Backup: Yes

* Entire System Backup: Yes

High Availability

* Synology High Availability: Yes

Log Center

* Syslog Events per Second: 800
