Dahua Coaxial Cable with Power Cable | 300M | Black and White | itw

Product Name:

Itw | Dahua Coaxial Cable with Power Cable | 300M | Black and White

BLACK: DH-PFM941I-RG6N/21-300B

Type: Coaxial Cable with Power Cable (2C)

Length: 300m

Color: Black Sheath

Certification: CPR Eca | RoHS 2.0 | REACH

Flame Retardant Rating: EN 50575 Eca

Features:

Integrated mini RG6 coaxial cable with 2-core power cable

Customized PVC sheath with anti-interference and anti-aging features

Ideal for CCTV, surveillance, or low-voltage video/power signal integration

Coaxial Cable Specs:

Conductor Material: CCS

Conductor Diameter: 1.02 mm ± 0.01 mm

Wire Gauge: 18AWG

Insulation Material: PE Foam

Insulation Diameter: 4.7 mm ± 0.15 mm

Shielding:

Inner: Single-sided aluminum foil, 15 mm wide

Outer: 16 × 8/0.12 mm Al-Mg Alloy

Braiding Density: ≥80%

Sheath: PVC, White, 6.8 mm ± 0.2 mm diameter

Impedance: 75 Ω ± 5 Ω

DC Resistance: ≤10.1 Ω per 100m

Power Cable (2C) Specs:

Conductor: CCA, 7/0.38 mm

Wire Gauge: 0.8 mm²

Insulation: PVC, Red & Black cores

Sheath: PVC, White, 3.3 mm × 5.1 mm ± 0.2 mm

DC Resistance: ≤3.8 Ω per 100m

Environmental Ratings:

Operating Temp: –20°C to +60°C

Installation Temp: 0°C to +50°C

Storage Temp: –10°C to +40°C, <60% RH

Packaging:

Cable Length: 300 m ± 1.5 m

Box Dimensions: 346 x 346 x 342 mm

Net Weight: 19.8 kg ± 0.5 kg

Gross Weight: 20.8 kg ± 0.5 kg

Box Qty per Pallet: 27 boxes

Pallet Size: 1100 x 1100 x 1195 mm

WHITE: DH-PFM941I-RG6N/21-300

Type: Coaxial Cable with Power Cable (2C)

Length: 300m

Color: White Sheath

Certification: CPR Eca | RoHS 2.0 | REACH

Flame Retardant Rating: EN 50575 Eca

Features:

Same technical build as black variant

White outer sheath for visual distinction in specific environments

Suitable for security installations and structured cabling setups

All technical specifications remain the same as above.
