MSI MAG B650 Tomahawk WiFi Gaming Motherboard (ATX, 11th/10th Gen Intel Core, LGA 1200 Socket, DDR5, CFX, M.2 Slots, USB 3.2 Gen 2, 2.5G LAN, DP/HDMI, Wi-Fi 6E, Mystic Light RGB)
- Supports AMD Ryzen™ 7000 Series Desktop Processors
- Supports DDR5 Memory, up to 6400+(OC) MHz
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
- 2.5G LAN and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs
- Lightning USB 20G: Built-in USB 3.2 Gen 2×2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1
- AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
SPECIFICATIONS
Chipset
- AMD B650
CPU Support:
- Supports AMD Ryzen™ 7000 Series Desktop Processors
- Socket AM5
Memory:
- 4x DDR5, Maximum Memory Capacity 128GB
- Memory Support DDR5 6600+(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz
Onboard Graphics
- 1x HDMI™
- 1x DisplayPort
- Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz*
- Support DP 1.4, maximum resolution of 8K 60Hz*
Expansion Slot
- 2x PCI-E x16 slot
- Support x16/ x4
- 1x PCI-E x1 slot
- PCI_E1 PCIe 4.0 supports up to x16 (From CPU)
- PCI_E2 PCIe 4.0 supports up to x4 (From Chipset)
- PCI_E3 PCIe 3.0 supports up to x1 (From Chipset)
Storage
- 3x M.2 slot
- M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
- M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
- M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
- 6x SATA 6G port
Raid
- Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices*
- Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
USB
- 2x USB 2.0 (Rear)
- 4x USB 2.0 (Front)
- 4x USB 3.2 Gen1 Type A (Rear)
- 2x USB 3.2 Gen1 Type A (Front)
- 3x USB 3.2 Gen2 Type A (Rear)
- 1x USB 3.2 Gen2 Type C (Front)
- 1x USB 3.2 Gen2x2 Type C (Rear)
LAN
- Realtek® RTL8125B 2.5Gbps LAN
Wireless / Bluetooth
- AMD Wi-Fi 6E
- The Wireless module is pre-installed in the M.2 (Key-E) slot
- Supports MU-MIMO TX/RX
- Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands
- Supports 802.11 a/ b/ g/ n/ ac/ axSupports Bluetooth® 5.2**
Audio
- Realtek® ALC4080 Codec
- 7.1-Channel High Performance Audio
- Supports S/PDIF output
- Supports up to 32-Bit/384 kHz playback on front panel
Internal I/O
- 1x Power Connector(ATX_PWR)
- 2x Power Connector(CPU_PWR)
- 1x CPU Fan
- 1x Pump Fan
- 6x System Fan
- 2x Front Panel (JFP)
- 1x Chassis Intrusion (JCI)
- 1x Front Audio (JAUD)
- 1x Tuning Controller connector(JDASH)
- 2x Addressable V2 RGB LED connector (JARGB_V2)
- 2x RGB LED connector(JRGB)
- 1x TPM pin header(Support TPM 2.0)
- 4x USB 2.0
- 2x USB 3.2 Gen1 Type A
- 1x USB 3.2 Gen2 Type C
LED Feature
- 4x EZ Debug LED
Back Panel Ports
- DisplayPort 1.4
- 2.5G LAN Port
- USB 2.0 Port
- USB 3.2 Gen 1 5Gbps Type-A
- Wi-Fi / Bluetooth Antenna
- HD Audio Connectors
- Flash BIOS Button
- HDMI™ 2.1 Port
- USB 3.2 Gen 2 10Gbps Type-A
- USB 3.2 Gen 2×2 20Gbps Type-C
- Optical S/PDIF OUT
Operating System
- Support for Windows® 11 64-bit, Windows® 10 64-bit
PCB Dimension
- ATX 243.84mmx304.8mm
