Product Name: Itw | Lenovo Laptop 83DA0009PH | Ultra 5 125H | LPDDR5x-7467 16GB | 512GB SSD | Intel Arc Graphics
Specification
PERFORMANCE
Processor: Intel® Core™ Ultra 5 125H, 14C (4P + 8E + 2LPE) / 18T, Max Turbo up to 4.5GHz, 18MB
NPU: Integrated Intel® AI Boost, up to 11 TOPS
Graphics: Integrated Intel® Arc™ Graphics
Chipset: Intel® SoC Platform
Memory: 16GB Soldered LPDDR5x-7467
Memory Slots: Memory soldered to systemboard, no slots, dual-channel
Max Memory: 16GB soldered memory, not upgradable
Storage: 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Support: One drive, up to 1TB M.2 2242 SSD
Storage Slot: One M.2 2280 PCIe® 4.0 x4 slot
Card Reader: microSD Card Reader
Optical: None
Audio Chip: High Definition (HD) Audio
Speakers: Stereo speakers, 2W x2, optimized with Dolby Audio™
Camera: FHD 1080p + IR with Privacy Shutter, ToF Sensor
Microphone: 2x, Array
Battery: Integrated 57Wh
Power Adapter: 65W USB-C® Slim (Wall-mount)
DESIGN
Display: 14" WUXGA (1920x1200) OLED 400nits Glossy, 100% DCI-P3, DisplayHDR™ True Black 500
Touchscreen: None
Keyboard: Backlit, English
Touchpad: Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
Case Color: Cloud Grey
Surface Treatment: Aluminium Stamping (Anodized with Sandblasting)
Case Material: Aluminium (Top), Aluminium (Bottom)
Pen: Pen Not Supported
Dimensions (WxDxH): 312 x 221 x 16.9 mm (12.28 x 8.7 x 0.67 inches)
Weight: Starting at 1.48 kg (3.26 lbs)
SOFTWARE
Operating System: Windows® 11 Home Single Language, English
Bundled Software: Office Home & Student 2021
CONNECTIVITY
Ethernet: No Onboard Ethernet
WLAN + Bluetooth: Wi-Fi® 6E, 802.11ax 2x2 + BT5.2
WWAN: Non-WWAN
Standard Ports
• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
• 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
• 2x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with USB PD 3.0 and DisplayPort™ 1.4
• 1x HDMI® 1.4b
• 1x Headphone / microphone combo jack (3.5mm)
• 1x microSD card reader
Monitor Cable: None
SECURITY & PRIVACY
Security Chip: Firmware TPM 2.0 Enabled
Fingerprint Reader: None
Other Security:
• IR camera for Windows® Hello (facial recognition)
• Camera privacy shutter
